AI analysis says: "You have a phenomenal system here!" Masterful mosaic geometry with Cozycrete's standard panel sizes.
Finite Element Analysis Report
Note that the report is for a single panel. The backing of polyiso, cast in place concete, and the interior panel are not factored in here.
I'm seeking architects, engineers, builders, and prospective home owners to say, "This is Great, I'll help you produce this to the maximum!"
I need your help, your intervention, cooperation, and team play. I've taken this as far as I can on my own. I need to pass the baton to YOU!
The barrier has been the lack of a PE to embrace the system. AI has validated all claimed features, but new innovation is a learning curve apparently very few wish to engage. A dominant new criteria has come to rule the roost, called Finite Element Analysis, ultimately creating a "Revit" model to plug into construction design. This system is now undergoing that analysis with results expected soon.
The system can be designed to any strength, including E5 tornado resistance. With extreme weather always increasing, homes need to be secure and insurance expense needs to be held in check, if not eliminated.
This is made possible by the fact that precision molds can replicate their precision into concrete castings. High performance features are simply replicated endlessly. A perfect weight, variety, and maximum durability are done with a minimum of materials and expense. Given the mold, anyone can do it.
The above approach having the massive concrete fill was due to the structural component of the system panels was completely ignored. They were considered non performing cladding.
Invented by Walt DeVore
Industrial Engineer
Georgia Tech, 1973
Idaho Springs, CO, 80452
USA
Cell and WhatsApp: 720 227 4524
Patent No. 5,802,793
Credentials
An Industrial Engineer is a problem solver. When something innovative needs to be implemented, a system solution is created particularly paying attention to the "devil in the details".
Here is a step drawing of the smallest 12" x 16" complete with the embedded expanded steel and the concrete it would displace within its mounting rib removed.
Interesting oxymoron, hard cold concrete being cozy. Yet, when the wall temperature is above room temperature, concrete emits a long wave infrared radiation which gently and penetratingly warms objects within a space. In fact, the penetrating nature of it allows a four degree temperature warmer sensation with a corresponding thermostat setback. Occupants report never having felt so "cozy". The infrared comes from the floor, all four walls, and the ceiling for full immersion.
I've been in suspense for thirtyfive years if another system could out perform this. If there was one, I'd quit in an instant since any more work would be futility and foolish. But there isn't, and I don't think there can be because of a fundamental law of physics. That is that the structural stiffness of a wall increases with the cube of its thickness. Put your strongest material as far as possible from the neutral axis, (where tensile force goes to zero and then transitions to compression). As material approaches the middle of a wall, its contribution to stiffness (not bending) goes to zero. This system has the 1 1/8" concrete wall faces, (average between 2" thick ribs and 1/2" thick webs) give a structural stiffness of 9-1/4" of regular cast in place concrete.
The concrete wall faces are an absolute bare minimum of concrete to be structurally sound. The steel joinery of the faces converts the two wall faces into a monolithic unit.
With the increasing popularity of "bunkers", a common sense choice for protection in a dangerous world, this system is ideally suited. For underground construction, the cavity wall air space shields moisture penetration.
Executive Summary
Appropriate Housing for a Challenged Humanity
Built the coast of British Columbia to the Los Angeles and Tokyo Earthquake Codes, a Proven System
The devastation of people's homes from increasingly violent weather is a tragedy that we must confront and do better. My initial forays into AI has it being called "Fortress" construction. That sounds like it would be a hopelessly expensive and unattainable. However, it's not, because of efficiencies and bulk materials inherent to the system.
The key is mega mass, streamlining construction processes, creating a precision product from bulk pea gravel concrete using molds developed over decades of evolution. Installation uses a wall map indicating placement of what goes where, easy installation of electrical and plumbing, and versatility as to what systems, ideas, and innovations are possible within the cavity wall. The product is lightweight enough to be handled and installed manually by unskilled labor. The greatest skill required is flat level concrete finishing for the slab or footing which the wall will be erected. There's a somewhat meticulous onus on the designer to specify everything, yet the performance of the system can be mind boggling. One utilizes a post tensioned concrete roof supported on all four sides by spandrel beams, eliminating column line droop and simplifying calculations. The overlaying concrete diaphragm ties it all together for a monolithic response and ductility. One may grasp this instantly or one can give it time to reveal its efficacy.
This is my singular creation and I'm looking for help and talent to turn this into a self turning wheel.The devastation of people's homes from increasingly violent weather is a tragedy that we must confront and do better. My initial forays into AI has it being called "Fortress" construction. That sounds like it would be a hopelessly expensive and unattainable. However, it's not, because of efficiencies and bulk materials inherent to the system.
This is my singular creation and I'm looking for help and talent to turn this into a self turning wheel.
Quick Summary of Why This is the Inevitable Best Choice
Glass smooth beveled wall faces for timeless cut stone aesthetic.
Completely fireproof.
Wall faces couple together for the widest and most efficient structural stiffness footprint.
System a "container" or "cavity wall" amenable to any appropriate bulk fill.
Tongue and grooved joints provide sealing, alignment, reinforcement, and unequaled ductility for maximum surviveability.
Easily and economically buildable to survive the most powerful servings of Nature.
Easy jobs for anyone to make profound contribution from precasting the panels and installing them.
Stretches concrete to maximum efficacy, only 14.7 pounds per square foot.
Mega mass floor, walls, and ceiling all infrared radiators for cozy even heat with and a 4 degree lower thermostat setting. Infrared radiance feels warmer with penetrating coziness.
System eliminates framing, sheathing, wrap,siding, and drywall. Walls fireproof, supports post tensioned concrete roof slabs
Precast concrete wall face units with embedded steel that overlap and fasten, in tandem with groove and spline (tongue and slot) for alignment, reinforcing, and sealing with a pvc strip. Characterized by AI as "Fortress Construction". Surprisingly low cost.
Projects with the Concrete Building System LLC
Note the mosaic patterns artfully created combining different panel sizes
Fastening
To have a quarter inch cover at each wall face on a 12” wide wall, the steel combination is 11 ½” which creates this overlap. Very easy for tack welding.
Forming
Couplers align vertically and horizontally. They support a formboard however one wishes. The cavity is easily partitioned so bulk fill such as crusher fines can be filled first and adjacent to it cast in place concrete. This gives the ability to use cast in place concrete around door and window frames to maximize strength against tornados, etc. Threaded inserts can be added to bolt opening protection such as expanded steel.
If wall removed, columns and beams can be formed judiciously within cavity
Fundamentals of Concrete Building System
Glass smooth surface
Cut stone beveled edges timeless appeal
Amenable to myriad decorative concrete finishes or left plain
Scant use of concrete at 14.7 pounds per square foot
Panels easy to make with highly evolved molds
Easy to manually install with basic wall maps
Wide wall footprint maximum rigidity (stiffness)
Plumbing and electrical simple installation within cavity
Trade labor minimal
Framing, sheathing, paper wrap, siding, and drywall all eliminated
It's the versatility that separates this from other options. The open wall cavity is a cornucopia for applications. It can be filled with everything from cast in place concrete, sand, gravel, crusher fines, or even plain dirt. It's never been easier, cheaper, and greener to get critically important mass to resist the increasingly severe forces of Nature.
Insulation is placed either against the interior panel or exterior panel. It depends on what the smartest application is dependent on the function. If against the exterior, then the cavity fill is part of the interior thermal mass. This adds a lot more thermal storage to stay warm or cool longer. But, it also requires a longer time to bring the interior mass up to temperature.
If against the interior panel then the exterior panel concrete becomes monolithic with the cast in place and one has a thick solid concrete exterior to withstand about anything.
Approximate Rule of thumb is that 3.3 square feet of panel are required for each square foot of floor space.
The first layer of horizontal rebar, if any, is tied into place along with the vertical rebars. Then a one layer course of concrete is deposited to lock it all in, Then one is ready to be off to the races.
Mold precision and resultant panel precision lets everything fit quickly. Descrepancies are identified and solved to not get thrown off.
The wall cavity is filled with chosen material to within specified inches from the top. The fill then supports cast in place concrete for the bond/spandrel beam which ties all the walls together in monolithic fashion.
Design phase tedious but can pinpoint function of every panel. Recording the number and size of each panel for each wall generates a materials list for the totality of panels required. Any special requirements for panel inlays are specified in the part number of the panel.
A timeless enduring concept, increasing strength by decreasing the dead load of concrete. The Pantheon has survived natural calamities since 128 AD. Concrete in compression can't be beat.
Two ways to displace concrete below:
Therefore, 40% of weight and cost and carbon footprint
Insulates half of the surface area for a net panel R value of 2.89. Polyiso added to the backside brings it up to any desired value.
The embedment extends to a quarter inch of the face for a depth of 1 ¾”, pull out strength 700 pounds, more or less depending on mix design, admixtures, fiber type and amount. That is over an area of 16" tall and 12" wide, or 1.33 sq ft. The pull out per sq ft is 700/1.33 =
2-1/2 Diamond and 2 diamond length of 12" wall, 8" cavity, insulation placed against longer coupler
Strand cross sectional area =0.0174 sq in, Strand surface area (4 faces) per inch = 2 x (0.115 x 0.151) 2 x (0.115 x 0.115) = 0.03473 + 0.02645 =[0.06118 x 4 strands] 0.24472 square inches. When encased in concrete all of that is the conductive area to be causing "thermal bridging". Yet when that area becomes "throttled" from being tightly encased in polyiso, the conductive path is restricted to the steel strand cross sectional area which equals 0.035 square inch for 4 strands which is an 85% restriction. That's like 7 lanes of traffic merging into one lane. What happens? A severe bumper to bumper slow down traffic jam.
Insight from AI
Your math regarding the physical geometry and the cross-sectional area change is spot on, but looking at it through the lens of heat transfer physics, comparing surface area to cross-sectional area tells a slightly different story about what is actually happening to the heat flow.
Here is a breakdown of why that ~85% reduction in area occurs geometrically, and how it impacts thermal conductivity:
Strand Surface Area (Encased in Concrete): When embedded in a solid matrix like concrete, the entire outer perimeter/surface area of the metal strands ($0.24472 \text{ sq in}$ per inch of length) is in intimate contact with the medium. Heat can transfer across this entire interface.
Cross-Sectional Area (In Polyiso): When you shift to a tight polyiso encasement or isolate the profile down to just the solid metal pathways, the effective area available for longitudinal heat conduction along the profile's axis drops to the actual metal cross-section ($0.035 \text{ sq in}$).
The Reduction: Dropping from a boundary/contact-driven surface footprint down to the bare metal's cross-sectional area is indeed a massive geometric constriction.
While the geometric area drops by roughly 85%, heat transfer is governed by material conductivity (Fourier's Law), not just contact area.
The Conductivity Contrast: Steel has a high thermal conductivity (roughly $45 \text{ to } 50 \text{ W/m}\cdot\text{K}$), whereas concrete has a much higher conductivity than polyiso ($0.8 \text{ to } 1.15 \text{ W/m}\cdot\text{K}$ vs. polyiso's paltry $\sim0.022 \text{ W/m}\cdot\text{K}$).
The Bottleneck is the Insulation: When the expanded steel goes from concrete into polyiso, the polyiso itself acts as an extreme thermal blanket. Even if the steel strands maintain their full cross-sectional area inside the foam, polyiso restricts overall heat loss so effectively that the steel acts as a localized thermal bridge.
Area vs. Flux: The 0.035 sq in cross-section represents the metal's path for heat to travel down the length of the strands. However, because polyiso surrounds it with an exceptionally high thermal resistance, very little heat can actually reach or escape through the sides of the strands compared to when they were embedded in thermally-conductive concrete.
Your calculation of the dimensional bottleneck is correct—transitioning from the total surface footprint to the isolated structural cross-section cuts the available conductive footprint by about 85%. However, rather than the steel "throttling" the heat, the polyiso is overwhelmingly dominating the thermal resistance, rendering the metal's internal geometry a secondary factor compared to the massive drop in matrix conductivity.
Python
# Let's model a 1-D steady-state thermal resistance network (parallel path or equivalent U-factor method)
# Layer thicknesses (inches):
# 1. Warm side concrete: 4.75 in
# 2. Polyiso insulation: 3.0 in
# 3. Cold side concrete: 1.75 in
# Let's define typical thermal conductivities (k in BTU * in / (hr * ft^2 * °F) or W / (m*K)):
# Concrete k ≈ 1.0 BTU/hr·ft·°F (approx 12 in thickness-normalized) -> let's use standard SI or Imperial U-value / R-value units:
# R-value per inch:
# Polyiso: ~5.6 to 6.5 per inch (let's use 6.0 hr·ft²·°F / BTU per inch)
# Normal weight concrete: ~0.083 to 0.10 hr·ft²·°F / BTU per inch (or 1.0 BTU/(hr·ft·°F) -> R-value per inch = 1/12 = 0.0833 hr·ft²·°F / BTU per inch)
# Let's write a quick script to calculate R-values per unit area (sq ft) for the layers:
thick_warm_concrete = 4.75 # inches
thick_polyiso = 3.0 # inches
thick_cold_concrete = 1.75 # inches
# R-value per inch:
r_per_in_concrete = 1.0 / 12.0 # (hr·ft²·°F/BTU) per inch roughly, or let's look at typical values.
# Actually, let's look at standard R-values:
# Concrete: ~0.08 R-value per inch
# Polyiso: ~6.0 R-value per inch
r_warm_concrete = thick_warm_concrete * 0.08
r_polyiso = thick_polyiso * 6.0
r_cold_concrete = thick_cold_concrete * 0.08
total_r = r_warm_concrete + r_polyiso + r_cold_concrete
u_factor = 1.0 / total_r
print(f"Warm concrete R: {r_warm_concrete}")
print(f"Polyiso R: {r_polyiso}")
print(f"Cold concrete R: {r_cold_concrete}")
print(f"Total R: {total_r}")
print(f"U-factor: {u_factor}")
The concrete embedment on one side of the polyiso is 4.75 inches, then the 3 inches of polyiso with then a 1 3/4 inch embedment on the cold side. Can one deduce the net conductance value?
# Let's model a 1-D steady-state thermal resistance network (parallel path or equivalent U-factor method)
# Layer thicknesses (inches):
# 1. Warm side concrete: 4.75 in
# 2. Polyiso insulation: 3.0 in
# 3. Cold side concrete: 1.75 in
# Let's define typical thermal conductivities (k in BTU * in / (hr * ft^2 * °F) or W / (m*K)):
# Concrete k ≈ 1.0 BTU/hr·ft·°F (approx 12 in thickness-normalized) -> let's use standard SI or Imperial U-value / R-value units:
# R-value per inch:
# Polyiso: ~5.6 to 6.5 per inch (let's use 6.0 hr·ft²·°F / BTU per inch)
# Normal weight concrete: ~0.083 to 0.10 hr·ft²·°F / BTU per inch (or 1.0 BTU/(hr·ft·°F) -> R-value per inch = 1/12 = 0.0833 hr·ft²·°F / BTU per inch)
# Let's write a quick script to calculate R-values per unit area (sq ft) for the layers:
thick_warm_concrete = 4.75 # inches
thick_polyiso = 3.0 # inches
thick_cold_concrete = 1.75 # inches
# R-value per inch:
r_per_in_concrete = 1.0 / 12.0 # (hr·ft²·°F/BTU) per inch roughly, or let's look at typical values.
# Actually, let's look at standard R-values:
# Concrete: ~0.08 R-value per inch
# Polyiso: ~6.0 R-value per inch
r_warm_concrete = thick_warm_concrete * 0.08
r_polyiso = thick_polyiso * 6.0
r_cold_concrete = thick_cold_concrete * 0.08
total_r = r_warm_concrete + r_polyiso + r_cold_concrete
u_factor = 1.0 / total_r
print(f"Warm concrete R: {r_warm_concrete}")
print(f"Polyiso R: {r_polyiso}")
print(f"Cold concrete R: {r_cold_concrete}")
print(f"Total R: {total_r}")
print(f"U-factor: {u_factor}")
To do this, engineers use a thermal resistance network (analogous to electrical resistors in series). Because you have specific layer thicknesses sandwiching the insulation, you can calculate the total resistance ($R$-value) and invert it to find the net conductance.
1. Establish Thicknesses
Warm-side concrete: 4.75"
Polyiso insulation: $3.0 \text{ inches}$
Cold-side concrete: $1.75 \text{ inches}$
2. Apply Typical Material Resistances ($R$-values per inch)
Normal-weight concrete: $\approx 0.08 \text{ (hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU)}\text{ per inch}$
Polyiso foam board: $\approx 6.0 \text{ (hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU)}\text{ per inch}$
3. Calculate Layer Resistances ($R = \text{thickness} \times r_{\text{per inch}}$)
$R_{\text{warm concrete}}$: $4.75 \text{ in} \times 0.08 = 0.38 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$
$R_{\text{polyiso}}$: $3.0 \text{ in} \times 6.0 = 18.0 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$
$R_{\text{cold concrete}}$: $1.75 \text{ in} \times 0.08 = 0.14 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$
4. Total Thermal Resistance ($R_{\text{total}}$)
Since the heat must flow straight through these layers in series, you sum their resistances:
$$R_{\text{total}} = 0.38 + 18.0 + 0.14 = 18.52 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$$
5. Net Conductance ($U$-factor)
The net conductance is the reciprocal of the total thermal resistance ($U = 1 / R_{\text{total}}$):
$$U = \frac{1}{18.52} \approx 0.054 \text{ BTU/(hr}\cdot\text{ft}^2\cdot^\circ\text{F)}$$
The Polyiso Dominates: Notice that out of the total $18.52$ resistance, the $3\text{-inch}$ layer of polyiso contributes $18.0$ of it ($\approx 97\%$). The concrete layers on either side provide almost zero thermal barrier by comparison.
The Thermal Bridge Effect: Because the expanded steel strands run continuously through this sandwich, they act as a high-conductivity thermal bridge punching right through that $18.0$-resistance insulation barrier. Even though the polyiso successfully throttles the bulk matrix heat transfer down to a low $U$-factor of $0.054$, heat will preferentially "sneak" along the metal strands, creating localized heat flux concentrations wherever the steel breaches the insulation envelope.
There is one steel bridge for every 1.33 sq ft of wall. The average polyiso thickness for that area is 3.75 sq inches. Given the conductance through the steel, what is the overall R value per square foot of the wall?
There is one steel bridge for every 1.33 sq ft of wall. The average polyiso thickness for that area is 3.75 sq inches. Given the conductance through the steel, what is the overall R value per square foot of the wall?
To find the overall $R$-value per square foot of the wall, we use the parallel path method (ASHRAE zone/isothermal planes method) to account for the thermal bridging of the steel strands cutting through the polyiso layer.
Steel cross-sectional area per bridge: $0.035 \text{ sq in}$
Wall area per bridge: $1.33 \text{ sq ft} = 1.33 \times 144 = 191.52 \text{ sq in}$
Steel area fraction ($f_{\text{steel}}$):
$$\frac{0.035 \text{ sq in}}{191.52 \text{ sq in}} \approx 0.000183 \quad (0.0183\%)$$
Polyiso area fraction ($f_{\text{polyiso}}$):
$$1 - 0.000183 = 0.999817 \quad (\approx 100\%)$$
Polyiso Insulation Layer ($3.75\text{ in}$ at $\sim 6.0\text{ R/in}$):
$$R_{\text{polyiso}} = 3.75 \times 6.0 = 22.5 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$$
Steel Bridge Layer ($3.75\text{ in}$ length, with carbon steel conductivity $\approx 312 \text{ BTU}\cdot\text{in}/(\text{hr}\cdot\text{ft}^2\cdot^\circ\text{F})$):
$$R_{\text{steel}} = \frac{3.75}{312} \approx 0.012 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}$$
Using the parallel resistance formula for the insulation plane:
$$\frac{1}{R_{\text{bridged}}} = \frac{f_{\text{steel}}}{R_{\text{steel}}} + \frac{f_{\text{polyiso}}}{R_{\text{polyiso}}}$$
$$\frac{1}{R_{\text{bridged}}} = \left(\frac{0.000183}{0.012}\right) + \left(\frac{0.999817}{22.5}\right) \approx 0.01525 + 0.04444 = 0.05969$$
$$R_{\text{bridged}} = \frac{1}{0.05969} \approx \mathbf{16.77 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}}$$
(Notice how the high thermal conductivity of the steel pulls the effective $R$-value of the $3.75\text{-inch}$ insulation layer down from $22.5$ to about $16.77$ due to thermal bridging.)
Adding back the non-bridged concrete layers from the previous assembly ($0.38$ for the warm side + $0.14$ for the cold side):
$$R_{\text{total}} = R_{\text{concrete (warm)}} + R_{\text{bridged layer}} + R_{\text{concrete (cold)}}$$
$$R_{\text{total}} = 0.38 + 16.77 + 0.14 = \mathbf{17.29 \text{ hr}\cdot\text{ft}^2\cdot^\circ\text{F/BTU}}$$
Even though the steel bridges represent a tiny fraction of the wall area ($\sim0.02\%$), their extreme conductivity creates a thermal bypass that degrades the effective $R$-value of the $3.75\text{-inch}$ polyiso core from its nominal $22.5$ down to a net wall assembly $R$-value of roughly $17.3$ (an effective overall U-factor of 0.058.
Switching from standard wood framing to high-mass concrete construction (such as insulated concrete forms [ICFs], solid concrete walls with exterior rigid insulation, or structural mass walls) completely changes how a wall handles energy, code compliance, and moisture dynamics—especially in a severe mountain environment like Clear Creek County (Climate Zone 7).
High-mass concrete affects building performance and code requirements in several distinct ways:
Under the 2021 IECC, mass walls (where the structural mass of concrete provides the thermal mass) have a separate compliance path from wood-frame walls:
The Prescriptive Mass Wall Rule: For Climate Zone 7, the 2021 IECC requires a minimum of R-15 continuous insulation (ci) on the exterior (or R-21 if placed entirely on the interior, though exterior placement is vastly preferred).
Comparison to Wood Framing: While a standard wood-frame wall in Zone 7 requires a complex combination like R-20 + R-5 continuous insulation (due to heavy thermal bridging through wood studs), high-mass concrete walls benefit from structural continuity. However, because concrete itself has an R-value of practically zero (roughly R-0.1 per inch), the entire insulation requirement must be met via continuous insulation layers.
Concrete has high thermal mass, meaning it absorbs, stores, and slowly releases thermal energy over time:
Smoothing Temperature Swings: In the high Rockies, daytime temperatures can be warm while nighttime temperatures plummet. Concrete acts like a thermal "battery." It absorbs heat during the day and slowly releases it into the home at night, flattening out extreme indoor temperature spikes.
The Catch: Thermal mass does not act as insulation—it just delays heat flow. Without adequate continuous insulation (the code-minimum R-15 or higher), concrete will quickly bleed heat to the freezing mountain air.
Where you put the insulation relative to the concrete core is vital for preventing structural moisture failure:
Exterior Insulation (Recommended): Placing rigid foam insulation on the outside of the concrete keeps the heavy concrete mass warm and within the conditioned space of the home. Indoor moisture can safely migrate through the wall and dry inward without hitting a freezing condensing surface.
Avoiding Interior Vapor Barriers: In high-mass concrete construction in cold climates, you must avoid putting a plastic interior vapor barrier (like 6-mil poly) directly against the concrete or inner framing. The wall needs to be vapor-open on the interior so it can breathe and dry properly.
While the legal baseline under the energy code for a mass wall is R-15 continuous insulation, many high-altitude mountain builders and engineers push that closer to R-20 or R-25 (such as thicker ICF blocks or added exterior rigid board). At 8,000 to 10,000 feet elevation, exceeding the minimum baseline drastically cuts down on long-term heating loads and keeps your backup heating systems from running continuously through deep winter.
Code output
Warm concrete R: 0.38
Polyiso R: 18.0
Cold concrete R: 0.14
Total R: 18.52
U-factor: 0.053995680
The steel overlap is tack welded. The tack welding came along a little later as the bolt, nut, washer assembly would allow some slippage sliding apart of the panels due to the pressure of deposited concrete. Tack welding eliminated the problem. However, if the panels are used in a temporary application, say blast protection in a war zone, the bolt nut method would be fine. The cavity could be filled with sand and then later removed through access openings in the bottom of the wall. The efficacy of sand for force absorption is evident on a runaway truck ramp outside Denver that is on a steep downhill grade. Plastic barrels full of sand are deployed to somewhat gently bring a big rig to a halt that has burned up its brakes.
Splines align and seal the panel seams
Finished wall system from beginning giving a maintenance free, fireproof and waterproof home
for aesthetic interest
Installation jig that locks in panel spacing
Electrical boxes and plumbing sleeves cast into panel
Conduit supported on top of couplers
Not the right mixer for the aggregate but made it work anyway
Last place for a 6'4" guy to be
Bosch Hammer Drill chips away
Everyone welcome to play
16"specialty panel coupler spacing
18" specialty panel coupler spacing
24" coupler spacing, 2" wide ribs, 4"x12" voids, 2" horizontals, 1" ends, 38 pounds of concrete, 14.7 pounds /sqft
